PTFE Seat Stainless Steel Bettis Actuated Butterfly Valves

The TTV Stainless Steel Actuated PTFE Seated Butterfly Valves offer comparable corrosion resistance to standard valves, with added external protection in environments where chemicals are present or during washdown procedures. With its field-serviceable modular configuration, Bettis actuators can be easily altered from single-acting to double-acting and equipped with a hydraulic manual override after installation. This adaptability adds an extra measure of versatility, allowing for customised solutions to meet specific operational needs.

Key Features

Key features and benefits of the 40WP4040F0BE Actuated Butterfly Valves.

Key Features

Meeting both IP66 and IP67M specifications for submergence and high-pressure water deluge tests, Bettis offers superior water ingress and corrosion protection. This robust design ensures longevity and reliability even in harsh environmental conditions, making it ideal for a wide range of applications.

Key Features

Featuring over fifteen alerts and alarms, the built in Bettis system provides comprehensive monitoring, promptly notifying users of any abnormalities within the system. This proactive approach enhances operational safety and efficiency by enabling quick responses to potential issues, minimising downtime and mitigating risks.

Key Features

TTV's PTFE stainless steel butterfly valves offer reliable protection for your most demanding applications. These versatile pieces of equipment can be used both externally and internally, in environments where extreme corrosion is expected or required.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Frequently Asked Questions

The Bettis range is designed to handle pneumatic media for optimal performance.

Pneumatic actuators in the Bettis range typically operate within a supply pressure range suitable for pneumatic actuation.

The Bettis range offers fail-safe, quarter-turn, spring-return, and double-acting actuation options to suit various application requirements.

The Bettis range is certified with ATEX and PED certifications, ensuring compliance with European safety standards.

Bettis actuators support on/off control for efficient and straightforward operation.

Bettis actuators are compatible with various valve types, including ball valves, butterfly valves, plug valves, triple offset valves, and other quarter-turn devices.

The standard operating temperature range for Bettis actuators is from -20°F to +200°F (-29°C to +93°C), with optional ranges available to -40°F (-40°C) or up to +350°F (+177°C).

Bettis actuators boast a torque/thrust capacity of up to 1,200,000 lbf-in (135,000 Nm), ensuring robust performance across a range of applications.

The standard operating pressure for Bettis actuators is either 60 or 80 psig (4 or 5.5 Bar), providing optimal performance within specified parameters.

Yes, Bettis actuators offer optional temperature ranges to accommodate extreme temperature environments, ensuring reliable operation in diverse conditions.

Yes, Bettis actuators offer fail-safe actuation options, providing added reliability and safety for critical applications.

Yes, Bettis actuators are designed for straightforward integration with various valve types and control systems, facilitating seamless automation of industrial processes
