High-performance Double Offset Butterfly Valves are designed for use in exceptionally harsh conditions with critical shutoff isolation and throttling control applications. The aptly named Colossus is available as a Metal Seated or PTFE seated design. The Colossus is one of our most reliable products because it's made from high-quality materials that can withstand the harshest conditions while still working reliably over long periods of time with minimal maintenance required. Lugged butterfly valves are a great choice for applications where you need to be able to disconnect the piping from either side of the valve. These lugged connect style butterfly valves feature a built in alignment guide through its bolt holes on both sides.

Shop

Key features and benefits of the Colossus TTV Lugged Pattern High Performance Butterfly Valves.

Key Features

Firesafe Butterfly Valves are now more commonly being used over that of equivalent sized Gate, Globe & Ball Valves where weight, budget and space saving is a priority. A single piece shaft design brings high strength engineering with Stem extensions also available.

Key Features

TTV Butterfly Valves feature an innovative disc design that greatly increases Cv values resulting in lower energy costs and improved efficiency with no sacrifice in performance or durability compared to other manufacturers valves on the market.

Key Features

All butterfly valves are rigorously tested to meet ever-changing industry requirements with our research and development team constantly creating design improvements to future proof the next generation. Typical applications include HVAC, Power Generation and Hydro Carbon Processing.


Body Material:	Stainless Steel CF8M, Cast/Carbon Steel A216 WCB
Disc Materials:	Stainless steel (CF-8M)
Shaft Materials:	Stainless Steel F-316
Design:	API 609, ASME B16.34, MSS SP-67, EN 593, Nace MR 0175
Inspection & Testing:	ISO 5208 / API 598
Connections:	ISO 5752 series 20, BS 5155 series 4, DIN PN 10/16/25, ANSI 150/300
Seat Materials:	Soft seat: R-PTFE (-50ºC / +220ºC), Hard seat: F-316L (-100ºC / +500ºC)
Applications:	Chemical, Vacuum, LPG/LNG, Hydrocarbons, Steam, Gas, Bitumen, Thermal Oil

The valve is suitable for almost all chemical applications. Send in an email of pick up the phone. One of our super tech guys will check it over for you.

We can. The final is product customizable at the bottom of the page! Have a look down there or get us on 0151 547 1221. We have everything from Safe Area to ATEX in multiple voltages.

It certainly does. All of our PTFE butterfly valves come complete with a full set of operations and maintenance manuals from the manufacturer.

Yes we can. If you cant find what you are looking for on the website get in touch. We have valve switch boxes for all zoned and safe areas including LED visual indication.

Maybe. Give us a call to find out.

Metal - Metal Seat complies with BS 6755 Part 2 or API 6FA/607 (Fire Safety). Valve only.

A fully lugged and tapped butterfly valve features threaded lugs around the valve body, allowing it to be bolted directly between two flanges without the need for nuts. This design enables easy installation and removal from one side of the pipeline while maintaining system integrity on the other side.

Lugged butterfly valves provide greater flexibility in pipeline systems. They allow for dead-end service, meaning one side of the pipeline can be disconnected without affecting the other. This makes them ideal for maintenance, isolation, and more demanding industrial applications compared to wafer-style valves.

These valves are commonly used across water treatment, HVAC systems, chemical processing, and general industrial applications. Their robust construction and secure mounting make them suitable for both low and medium-pressure systems where reliable isolation is required.

Colossus fully lugged butterfly valves are typically available in a range of materials including ductile iron, carbon steel, and stainless steel bodies, with various disc and seat options such as EPDM, PTFE, or NBR. This allows them to be tailored for different media, temperatures, and operating conditions.

TopWorx Valve Limit Switch Box available for this product. Enable remote Valve monitoring of your High Performance Butterfly Valves with a world leading Valve Position Monitor. Safe Area, Explosion Proof, Intrinsically Safe. All available from stock with fitting and calibration to your Pneumatic Actuator prior to shipping.
