Actuation Valve provide fast turnaround times without sacrificing quality or expertise and all orders come with a two page test report detailing all opening/closing times on each valve tested. Whether you need one product or several hundred off-the-shelf parts, we can deliver. Position indicators available for the Actreg actuator include direct mounting puk sensors such as P&F, IFM and other manufactures depending on end user approved vendor lists (AVL’s). Position monitoring switch boxes and sensors are also available from stock for quick assembly. Easily identifiable in field operation with varied end cap design for double or single acting actuators without the need for labelling or serial code traceability if worn or removed. End caps are epoxy coated as standard protecting them against environmental corrosion.

Shop Help Me

Key features and benefits of AV-L6100AC Actuated Ball Valves.

Key Features

All of our Actuated Valve Assemblies are manufactured in house with the help from automation experts. Every completed unit comes equipped to meet high standards and can be traced back via two page test report detailing opening/closing times.

Key Features

The AV-L6100 Ball Valves are silicone free and suitable for use on oils based paint products and applications. This allows complete assurance that the Valve will not apply any contamination to the medium that could effect the end finish. Extremely important in car manufacturing.

Key Features

Position indicators available for the Actreg actuator include direct mounting puk sensors such as P&F, IFM and other manufactures depending on end user approved vendor lists (AVL’s). Position monitoring switch boxes and sensors are also available from stock for quick assembly.

	B	C	D	E	B	C	D	E
	SR	SR	SR	SR	DA	DA	DA	DA
1/2"	81.00	145.00	163.00	108.00	72.00	138.00	145.00	108.00
3/4"	81.00	149.00	163.00	117.00	72.00	142.00	145.00	117.00
1"	96.00	174.00	195.50	127.00	72.00	148.00	158.00	127.00
1 1/4"	96.00	186.00	195.50	140.00	72.00	160.00	158.00	140.00
1 1/2"	116.00	213.00	217.00	165.00	93.00	198.00	177.00	165.00
2"	116.00	219.00	217.00	178.00	93.00	204.00	177.00	178.00
2 1/2"	127.00	249.00	258.00	190.00	93.00	224.00	196.00	190.00
3"	140.00	277.00	299.00	203.00	106.00	247.00	225.00	203.00
4"	157.00	322.00	348.50	229.00	136.00	315.00	273.00	229.00
5"	197.00	404.00	473.50	356.00	166.00	390.00	372.00	356.00
6"	218.00	453.00	560.00	394.00	166.00	411.00	439.00	394.00
8"	248.00	533.00	601.00	457.00	181.00	479.00	461.00	457.00

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

DRAWINGS & SCHEMATICS

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.


Body Material:	ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material:	TFM 1600 PTFE Ball Seats
Body Seal Material:	Grafoil/316 Stainless Steel
Stem Packing Material:	Grafoil
Design Standard:	ASME B16.34
Wall Thickness:	ASME B16.34
Inspection & Testing:	API 598
Face 2 Face:	ASME B16.10

Yes, this Valve is suitable for water within the pressure and temperature limitations.

Not in its current format however we can offer both options. Get in touch through sales@actuation.co.uk or 0151 547 1221 and we will run through some safety options with you for quoting.

It certainly does. All of our actuated valves come complete with a full set of operations and maintenance manuals from both the valve and actuator manufacturers.

Yes, position feedback is included as standard on the AV-L6100AC range, with switches confirming open and closed positions.

Yes, discounts are usually available on multi-unit or bulk orders of the AV-L6100AC range. Get in touch with your required quantity and specification and our sales team will confirm the best pricing for your order.

Yes, the AV-L6100AC range can be supplied with SIL 2 certification for use in safety instrumented systems. Please confirm this requirement when ordering so the correct documentation is issued with your valve.

Yes, we can advise on larger sizes outside the standard AV-L6100AC range. Send us your line size and process details by email or give us a call and we will confirm availability and lead time.

Yes, we can deliver directly to your customer on a plain, unbranded label. Send us a copy of your delivery note and we will include it with the shipment so your customer receives it under your company name.

Yes, we offer credit accounts for trade and repeat customers, subject to a credit check. Apply on the product page at checkout or contact our sales team directly and we will guide you through the application process.

The BLX V100E Series is an Electro-Pneumatic control unit that allows the Actuator to incrementally adjust the Valve's position between the fully open and closed cycle. Product variants are available for spring return and double acting setups with feedback and safety settings. Ask our team today about how the V100E can help with your process requirements.

CERTIFICATES & APPROVALS
