3-Way BSPP Reduced Bore Actreg Actuator Valves

This multipart diverter valve package is a perfect choice for those who need to deal with medium aggressive water conditions and harsh external environments. It has been designed using only high quality materials from the manufacturer Kingdom Controls. Optional installation for both across line. The design of the Actreg actuator allows for both setups depending on application requirements where space saving may be required. A typical inline mounting would be for uses involving hopper line actuation and bagging lines. Stock range of couplings and brackets available to suit the Actreg range of actuators and any valves that require the linkages. This enables Actuation Valve to offer a quick lead time and turnaround for all actuated valve packages involving the Actreg unit.

Key Features

Key features and benefits of AV-L5000AC & AV-L5100AC Actuated Ball Valves.

Key Features

3-Way Ball Valves can be used to divert flow from one fluid flow path to another in industrial process systems. 3-Way Ball Valves are typically used in the process industry to connect, disconnect or redirect flow between two or more fluid flow paths.

Key Features

The AV-L5000 & 5100 3-Way Ball Valve is suited to Screwed connections and the stainless steel body houses either an L or T drilled ball configuration. The L port valve is drilled at 90 degrees from two different sides to resemble an L whereas the T also features one hole straight through.

Key Features

Actreg's Actuator is built for long-lasting, reliable performance with a wide variety of materials and options that allow you to specify alternate coatings that are best suited for your application requirements. The pneumatic actuators combine quality parts designed over many years by in field experts. All available at a competitive price point.

RB 3-Way Ball Valve Technical Stuff

1/4" 81.00 139.00 163.00 79.00 81.00 139.00 145.00 79.00
3/8" 81.00 139.00 163.00 79.00 81.00 139.00 145.00 79.00
1/2" 81.00 139.00 163.00 79.00 81.00 139.00 145.00 79.00
3/4" 81.00 145.00 163.00 88.00 81.00 145.00 145.00 88.00
1" 96.00 174.50 195.00 108.00 96.00 174.50 158.00 108.00
1 1/4" 96.00 178.00 195.00 124.00 96.00 178.00 158.00 124.00
1 1/2" 116.00 210.50 217.00 135.00 116.00 210.50 177.00 135.00
2" 116.00 219.80 217.00 164.00 116.00 219.80 177.00 164.00

RB 3-Way Ball Valve 3D Stuff

Actreg Actuator Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Valve Standards & Stuff

Body Material: ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material: TFM 1600 PTFE Ball Seats
Body Seal Material: PTFE
Stem Packing Material: PTFE
Design Standard: MSS SP-110
Wall Thickness: ASME B16.34 Class 400
Inspection & Testing: MSS SP-110
BSP Ends: BSPP IS0 228/1

Frequent Interrogation

Yes, this Valve is suitable for water within the pressure and temperature limitations.
Great. The Namur standard interface is perfect for direct mounting a pilot solenoid valve. We can supply this actuated valve for you with or without a solenoid valve.
It certainly does. All of our actuated valves come complete with a full set of operations and maintenance manuals from both the valve and actuator manufacturers.

Yes we can. If you cant find what you are looking for on the website get in touch. We have valve switch boes for all zoned and safe areas including LED visual indication.

Maybe. Give us a call to find out.
Most definitely. We will require some more information. Drop us an email or get in touch on the blower.
Yes we can. Plane label or with a big bow. Send us a copy of your delivery note and we will fix it to the box. Jop done.
We will need to talk to Big Tony. If he says you're good for the debt then everything is in order. You can apply for this on the product page or ask for Big Tony when you get in touch.

4-20mA Control Available On This Product

The BLX V100E Series is an Electro-Pneumatic control unit that allows the Actuator to incrementally adjust the Valve's position between the fully open and closed cycle. Product variants are available for spring return and double acting setups with feedback and safety settings. Ask our team today about how the V100E can help with your process requirements.

3-Way Valve Configuration

Multiple Valve configurations available depending on your application requirements. Request a copy configurator or give us a call and our 3-Way Experts will talk you through the options.
