Electric PN40 Stainless Steel Koei Unic Actuator Valves

The AV-L6N00EK DIN PN40 actuated ball valves provide a high pressure full flow operation with a bore of up to 8 inches. The actuated ball valves connections offer installation between two alternate flanges within a pipeline. Valve approvals include DNV, SIL 2, Lloyds Register & NACE MR-0175. Additional ball valve options include an upstream and cavity relief hold drilled into the ball and high temperature spindle extension for insulation and steam actuation. Express shipping for delivery within 24-48 hours for stock components. The Koei UNIC Electric Actuator features an easy to use Allen Key Manual Override, overload protection system and end of travel electric stop. It also includes a mechanical limit/mechanical switch for open and close indication on your control panel.

Key Features

Key features and benefits of AV-L6N00EK Actuated Ball Valves.
1

Key Features

Koei Actuators have been producing Electric Actuators from their factory in Japan since the beginning of 2000 and they've quickly established themselves amongst one the leading manufacturers for electric actuator sales.
2

Key Features

The AV-L6N00 line of stainless steel ball valves is designed with you in mind. They're easy to install and incredibly durable so you get the most out of your product without worrying about repairs or replacements down the road.
3

Key Features

UNIC Electric Actuator by Koei Industry was made specifically for continuous process applications where frequent start/stop cycles would damage a traditional motorised actuators. The Koei UNIC electric actuator allows you to increase productivity and reduce costs.

Flanged PN40 Technical Stuff

B C D E Model
1/2" 145.00 224.00 159.00 115.00 UNIC 05
3/4" 145.00 229.00 159.00 120.00 UNIC 05
1" 145.00 235.00 159.00 125.00 UNIC 05
1 1/4" 145.00 247.00 159.00 130.00 UNIC 05
1 1/2" 145.00 252.00 159.00 140.00 UNIC 05
2" 145.00 261.00 159.00 150.00 UNIC 05
2 1/2" 155.00 304.00 208.00 170.00 UNIC 10
3" 155.00 319.00 208.00 180.00 UNIC 10
4" 187.00 350.00 257.00 190.00 UNIC 20
5" 187.00 393.00 257.00 325.00 UNIC 40
6" 272.00 440.00 381.00 350.00 UNIC 60
8" 272.00 489.00 381.00 400.00 UNIC 60
10" TBA TBA TBA TBA TBA

Flanged PN40 3D Stuff

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Valve Standards & Stuff

Body Material: ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material: TFM 1600 PTFE Ball Seats
Body Seal Material: Grafoil/316 Stainless Steel
Stem Packing Material: Grafoil
Design Standard: ASME B16.34
Wall Thickness: ASME B16.34
Inspection & Testing: API 598
Face 2 Face: ASME B16.10

Frequent Interrogation

Yes, this Valve is suitable for water within the pressure and temperature limitations.

Not in its current format however we can offer both options. Get in touch through sales@actuation.co.uk or 0151 547 1221 and we will run through some safety options with you for quoting.

It certainly does. All of our actuated valves come complete with a full set of operations and maintenance manuals from both the valve and actuator manufacturers.

Yes! Position feedback is included as standard with switches for open and closed positions.

Maybe. Give us a call to find out.
No.
Most definitely. We will require some more information. Drop us an email or get in touch on the blower.
Yes we can. Plane label or with a big bow. Send us a copy of your delivery note and we will fix it to the box. Jop done.
We will need to talk to Big Tony. If he says you're good for the debt then everything is in order. You can apply for this on the product page or ask for Big Tony when you get in touch.

Fail-Safe Battery Backup

Fail-Safe Battery Backup is available for this product. In the event of a possible power failure the Actuator will return the Valve to a desired position. Ideal for critical line applications where safety is paramount. Will need some additional details from you. Pick up the phone and we will get you sorted faster than it takes Kipchoge to run a Marathon fuelled by 5 Red Bulls. Supercharged Customer Service.
