Valpes Actuators Actuated 2 Piece Wras Approved Valves

The AV-L4500VA offers dependable performance and compliance with WRAS standards, making them a reliable choice for various applications. With precision engineering and adherence to stringent quality standards, these valves provide peace of mind when it comes to fluid control. Trust Valpes Actuators for efficient, compliant valve solutions. VALPES focuses on the production, assembly, and testing of electric actuators in its manufacturing plant. This specialisation suggests a deep expertise in this specific product category, allowing for a dedicated and efficient manufacturing process.

Key Features

Key features and benefits of the AV-L4500VA 2 Piece WRAS Approved Valves

Key Features

The actuators are available in a standard 90° version, providing rotational movement within a 90-degree angle. Additionally, there are options for 180° or 270° versions upon request, allowing customisation based on specific application needs.

Key Features

The electric actuators in the Valpes VR Range boast a sturdy aluminium housing. This material provides excellent strength and resistance to environmental factors, ensuring the longevity and reliability of the actuators in various operating conditions.

Key Features

The inclusion of a manual override feature through an external shaft adds a practical dimension to the actuators. This feature allows for manual operation in situations such as power outages or during maintenance, providing a fail-safe mechanism and enhancing operational flexibility.

Wras Approved Actuated Ball Valves

WRAS approval is a mandatory requirement for any product that carries or receives drinking water from the public mains in the UK. It provides proof that our products have been tested by an independent body to ensure they meet all relevant standards and requirements as set out by Government. The AV4500 is a Wras Approved Ball Valve suitable for use drinking water.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Valve Standards & Stuff

Body Material: Brass CW 617 N
Seats Material: PTFE
Shaft Material: Brass CW 614 N
O-Rings Material: Viton
Ball Material: Brass CW 617 N
Approvals: Wras approved
Mounting: ISO 5211 Connection
End Connections: BSPP
Pressure Rating: PN40

Frequent Interrogation

WRAS (Water Regulations Advisory Scheme) approval means the valves meet regulatory standards for use in potable water systems in the UK. WRAS tests for materials, construction and performance.

Common materials are dezincification resistant brass or stainless steel. WRAS has requirements for leachable lead and other substances that could contaminate drinking water.

2-piece valves have the body and ball as one part, with the stem as the second part. This makes them more compact but non-serviceable. 3-piece valves can be disassembled for servicing.

Typical end connections are copper tube connectors, compression fittings and push-fit connectors. Threaded BSP or NPT connections are also sometimes used.

Common handles are cross type lever handles, tee handles and round knobs. Locking handles are also available to prevent tampering. Extended handles allow ease of operation in tight spaces.

Most 2-piece WRAS approved valves have pressure ratings of up to 400 psi (27 bar) and temperatures up to 230°F (110°C), with some high pressure models rated beyond this. Always confirm ratings for your application.

Many have full or near full-port openings to minimise flow restriction. Actual flow depends on valve size - 1/2” to 2" are common sizes for plumbing uses.

Typical applications are water supply lines, sinks, toilets, water heaters, washing machines, dishwashers and other household water control.

No special maintenance is required, just periodic inspection for leaks and smooth operation. Replacement is needed if a valve fails.

Most come with manufacturer warranties from 3-10 years depending on materials and brand. Some offer extended warranties against leaking.

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Frequently Asked Questions

The Valpes ER Range electric actuator is a precision-engineered device designed to provide controlled 90° rotational movement for a wide range of applications.

Yes, the electric actuator is equipped with a secured manual override, allowing manual operation during power outages or for maintenance purposes.

Valpes electric actuators are available in multiple torque options: 10-20-35-60-100 Nm, providing flexibility to meet diverse application requirements.

Yes, the long operating version also operates within the MULTIVOLT range, offering extended operating times from 34 seconds to 110 seconds for a 90° rotation.

Yes, the Valpes VR Range electric actuators adhere to the CE-ROHS-REACH Directives, ensuring compliance with European standards for safety, environmental protection, and the restriction of hazardous substances. This commitment underscores the dedication to product quality and regulatory standards.

Yes, the electric actuator allows for different possible rotation angles, enhancing its adaptability to diverse application needs.

Valpes electric actuators are designed with a duty rating of S4 50% (IEC34), indicating their suitability for intermittent operation with a duty cycle of 50%.

The Valpes VR Range electric actuators feature a sturdy aluminium housing, providing excellent strength and resistance to environmental factors for enhanced longevity and reliability in various operating conditions.

Valpes electric actuators are designed to operate within a temperature range of -50 °C to +70 °C, ensuring reliable performance in various environmental conditions.

The standard version operates within a voltage range known as MULTIVOLT, with operating times ranging from 6 seconds to 20 seconds for a 90° rotation.

Valpes electric actuators have an IP65, IP65, IP68 enclosure rating, providing protection against dust and water ingress, making them suitable for use in challenging and demanding environments.

Yes, users have the option to choose between a polyamide PA6 UL 94 V-0 or aluminium cover. The polyamide cover offers high flame-retardant properties (UL 94 V-0), suitable for applications where fire safety is a concern, while the aluminium cover provides additional strength and protection for applications with higher mechanical demands.
