Stainless Steel ANSI 150 Koei Unic Actuator Valves

Our stainless steel ball valves come pre-tested so you can get them up and running immediately. You will also receive a two page test report detailing all opening/closing times after your order has been completed. The AV-L6100 stainless steel ball valves can be used on oils based paints and coatings applications such as automotive refinishing. They're 100% silicone free so they won't contaminate your product or leave behind residue which can ruin your finish over time. The Koei UNIC electric actuator series offers a cost effective solution that delivers up to 30% more performance with lower operating costs compared to existing products on the market. They can be powered by AC or DC current.

Key Features

Key features and benefits of AV-L6100EK Actuated Ball Valves.
1

Key Features

The AV-L6100 Ball Valves are silicone free and suitable for use on oils based paint products and applications. This allows complete assurance that the Valve will not apply any contamination to the medium that could effect the end finish. Extremely important in car manufacturing.
2

Key Features

The Koei UNIC Electric Actuator is the most compact and innovative product on today's market. They will provide you with smooth operation over their entire speed range in high shock environments, so your equipment stays running smoothly 24/7.
3

Key Features

Thanks to its high-performance motor, this product is capable of operating at temperatures of -25 to 55 Deg C without sacrificing speed or power consumption. With its ability to operate in extreme environments this electric actuator is sure to deliver on all fronts when you need it most.

Flanged ANSI 150 Technical Stuff

B C D E Model
1/2" 145.00 225.00 159.00 108.00 UNIC 05
3/4" 145.00 229.00 159.00 117.00 UNIC 05
1" 145.00 235.00 159.00 127.00 UNIC 05
1 1/4" 145.00 247.00 159.00 140.00 UNIC 05
1 1/2" 145.00 252.00 159.00 165.00 UNIC 05
2" 145.00 258.00 159.00 178.00 UNIC 05
2 1/2" 155.00 304.00 208.00 190.00 UNIC 10
3" 155.00 314.00 208.00 203.00 UNIC 10
4" 187.00 350.00 257.00 229.00 UNIC 20
5" 187.00 393.00 257.00 356.00 UNIC 40
6" 272.00 440.00 381.00 394.00 UNIC 60
8" 272.00 489.00 381.00 457.00 UNIC 60
10" TBA TBA TBA TBA TBA

Flanged ANSI 150 3D Stuff

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Valve Standards & Stuff

Body Material: ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material: TFM 1600 PTFE Ball Seats
Body Seal Material: Grafoil/316 Stainless Steel
Stem Packing Material: Grafoil
Design Standard: ASME B16.34
Wall Thickness: ASME B16.34
Inspection & Testing: API 598
Face 2 Face: ASME B16.10

Frequent Interrogation

Yes, this Valve is suitable for water within the pressure and temperature limitations.

Not in its current format however we can offer both options. Get in touch through sales@actuation.co.uk or 0151 547 1221 and we will run through some safety options with you for quoting.

It certainly does. All of our actuated valves come complete with a full set of operations and maintenance manuals from both the valve and actuator manufacturers.

Yes! Position feedback is included as standard with switches for open and closed positions.

Maybe. Give us a call to find out.
No.
Most definitely. We will require some more information. Drop us an email or get in touch on the blower.
Yes we can. Plane label or with a big bow. Send us a copy of your delivery note and we will fix it to the box. Jop done.
We will need to talk to Big Tony. If he says you're good for the debt then everything is in order. You can apply for this on the product page or ask for Big Tony when you get in touch.

Fail-Safe Battery Backup

Fail-Safe Battery Backup is available for this product. In the event of a possible power failure the Actuator will return the Valve to a desired position. Ideal for critical line applications where safety is paramount. Will need some additional details from you. Pick up the phone and we will get you sorted faster than it takes Kipchoge to run a Marathon fuelled by 5 Red Bulls. Supercharged Customer Service.
Request more information or Advice

Please feel free to request information and advice using the form below or call us on 0151 541 8674
