Valpes Actuators Actuated ANSI 150 Carbon Steel Valves

Valpes Actuators' Actuated ANSI 150 Carbon Steel Valves offer reliable flow control for industrial applications, featuring durable carbon steel construction designed for high-pressure environments. These valves, compatible with ANSI 150 standards, ensure precise operation with Valpes' advanced actuator technology, suitable for a wide range of media. Ideal for industries requiring consistent performance and dependability, these actuated valves provide efficient and controlled flow management.
Shop Help Me

Key Features

Key features and benefits of the AV-L61C0VA Actuated Ball Valves.
1

Key Features

These valves are designed to meet ANSI 150 standards, making them ideal for high-pressure applications where reliable performance is crucial. The compliance ensures that the valves can seamlessly integrate into existing systems, offering compatibility and peace of mind for engineers and operators alike.
2

Key Features

Constructed from high-quality carbon steel, these valves are built to withstand harsh industrial conditions, including exposure to high temperatures and pressures. The material's inherent strength ensures a long service life, reducing maintenance needs and providing a cost-effective solution over time.
3

Key Features

Equipped with Valpes' advanced actuator technology, these valves offer precise control over flow rates, allowing for smooth and consistent operation. The precision actuation ensures that the valves can handle a variety of media with accuracy, improving overall system efficiency and reliability in critical industrial processes.

AV-L6KC0VA Ball Valve Technical Stuff

B C D B C D E
SR SR SR DA DA DA SR/DA
1/4" TBA TBA TBA TBA TBA TBA TBA
3/8" TBA TBA TBA TBA TBA TBA TBA
1/2" 72.00 120.00 137.00 72.00 120.00 137.00 59.00
3/4" 72.00 126.00 137.00 72.00 126.00 137.00 69.00
1" 72.00 130.00 137.00 72.00 130.00 137.00 83.00
1 1/4" 93.00 168.50 203.50 72.00 135.50 137.00 94.00
1 1/2" 93.00 180.00 203.50 84.50 163.00 153.50 102.00
2" 106.00 200.50 153.50 84.50 170.50 153.50 124.00
2 1/2" TBA TBA TBA TBA TBA TBA TBA
3" TBA TBA TBA TBA TBA TBA TBA

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Valve Standards & Stuff
Body Material: ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material: TFM 1600 PTFE Ball Seats
Body Seal Material: Grafoil/316 Stainless Steel
Stem Packing Material: Grafoil
Design Standard: ASME B16.34
Wall Thickness: ASME B16.34
Inspection & Testing: API 598
Face 2 Face: ASME B16.10

Frequent Interrogation

Yes, this Valve is suitable for water within the pressure and temperature limitations.

Not in its current format however we can offer both options. Get in touch through sales@actuation.co.uk or 0151 547 1221 and we will run through some safety options with you for quoting.

It certainly does. All of our actuated valves come complete with a full set of operations and maintenance manuals from both the valve and actuator manufacturers.

Yes! Position feedback is included as standard with switches for open and closed positions.

Maybe. Give us a call to find out.
No.
Most definitely. We will require some more information. Drop us an email or get in touch on the blower.
Yes we can. Plane label or with a big bow. Send us a copy of your delivery note and we will fix it to the box. Jop done.
We will need to talk to Big Tony. If he says you're good for the debt then everything is in order. You can apply for this on the product page or ask for Big Tony when you get in touch.

Valve Rubber Stamps

  • PDF
CERTIFICATES & APPROVALS

PED 2014/34/EU
  • PDF
CERTIFICATES & APPROVALS

ATEX
  • PDF
CERTIFICATES & APPROVALS

Firesafe API 607 5th Ed
  • PDF
CERTIFICATES & APPROVALS

SIL 2
  • Document
CERTIFICATES & APPROVALS

Nace MR-0175
  • PDF
CERTIFICATES & APPROVALS

Lloyds

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.
Request more information or Advice

Please feel free to request information and advice using the form below or call us on 0151 547 1221

Carbon Steel ANSI 150 Valpes Actuator Actuated Ball Valves
