Wafer Aluminium Bronze JJ Electric Actuated Valves

Construction materials including Bronze, Aluminium Bronze and Monel and additional High Alloy materials make Actuation Valve the first choice supplier to many leading Marine based companies with the ability to deliver rapid solutions for almost any application. J&J Electric Actuators offer a range of anti corrosive and durable electric actuators that are suitable for both indoor and outdoor environments for a complete corrosion resistance package. Our actuators have ingress protection to IP67 (Temporary Immersion) and are made from polyamide, making them resistant to corrosion.
Shop

Key Features

Key features and benefits of the 80WM580JJ Actuated Butterfly Valves.
1

Key Features

Bronze and aluminium bronze valves offer a high level of corrosion resistance to mediums such as water and salt water. These characteristics make bronze and aluminium a suitable for many applications within the Marine environment.
2

Key Features

The JJ electric actuators are built with rugged construction, high quality components and advanced technology to ensure maximum performance and durability over time. The JJ electric actuator is an affordable alternative that reduces downtime and maintenance costs.
3

Key Features

The TTV wafer pattern bronze butterfly valve is made of high quality bronze with bubble tight shutoff, strong corrosion resistance, long service life and is widely used in various industries including petroleum, chemical industry and marine.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Valve Standards & Stuff
Body Material: Aluminium Bronze
Seats Material: EPDM, NBR Buna, Hypalon, Viton, Silicone, High Temperature, Polyisoprene, Epichloridine
Design Standard: Concentric, Soft Seat
Face To Face: EN 558 Series 20, ISO 5752 Series 20, API 609 Table 1, BS 5155 Series 4
Pressure Testing: EN 12266-1, DIN 3230, BS 6755, ISO 5208
Connections: PN10/16 ANSI 150, ISO 7007, DIN 2501, BS 4504, ANSI Class 150 ANSI B16.5
Sealing Testing: ISO 5208, 100% Tight Shut Off, API 598

Frequent Interrogation

Yes, this actuated butterfly valve is suitable for water within the pressure and temperature limitations.

Great. The Namur standard interface is perfect for direct mounting a pilot solenoid valve. We can supply this actuated valve for you with or without a solenoid valve.

It certainly does. All of our actuated valves come complete with a full set of operations and maintenance manuals from both the valve and actuator manufacturers.

Aluminium bronze offers excellent corrosion resistance, high strength, and superior performance in seawater and marine environments, making it ideal for offshore, chemical, and process applications.

They are used across marine, oil and gas, desalination, water treatment, and chemical processing sectors where corrosion resistance and long service life are critical.

The wafer design allows the valve to fit snugly between two pipeline flanges, reducing weight and simplifying installation while maintaining a leak-tight seal when properly bolted.

JJ Electric Actuators are available in 24VDC, 110VAC, and 230VAC variants, ensuring compatibility with a wide range of site power supplies.

Yes. When configured with a modulating actuator, the valve can provide precise flow regulation using 4–20mA or 0–10V input signals.

Most models are rated to IP67, meaning they are dust-tight and protected against temporary immersion in water, suitable for indoor and outdoor environments.

Absolutely. The aluminium bronze construction provides excellent resistance to seawater corrosion and erosion, making it a preferred choice for marine and coastal systems.

Actuator Tech

  • PDF
DRAWINGS & SCHEMATICS

J4CS20
  • PDF
DRAWINGS & SCHEMATICS

J4CS35
  • PDF
DRAWINGS & SCHEMATICS

J4CS55
  • PDF
DRAWINGS & SCHEMATICS

J4CS85
  • PDF
DRAWINGS & SCHEMATICS

J4CS140
  • PDF
DRAWINGS & SCHEMATICS

J4CS300

Valve Rubber Stamps

  • PDF
CERTIFICATES & APPROVALS

Bureau Veritas
  • PDF
CERTIFICATES & APPROVALS

ABS
  • PDF
CERTIFICATES & APPROVALS

ATEX 2014/34/UE
  • PDF
CERTIFICATES & APPROVALS

ACS
  • PDF
CERTIFICATES & APPROVALS

PED 2014/68/UE
  • PDF
CERTIFICATES & APPROVALS

Lloyds ISO 9001

Choose Your Rubber

Material Applications Temperature
EPDM Water, Sea Water, Alcohols, Organic Salt Solutions, Mineral Acid Solutions, Mineral Based Alkalines -20°C +110°C
High Temperature EPDM Super Heated Water -20°C +130°C
NBR Buna Mineral & Vegetable Oils, Gas, Non Aromatic Hydrocarbons, Animal Fats, Vegetable Fats, Air -10°C +80°C
Hypalon Mineral Acid Solutions, Organic & In-Organic Acids, Oxidising Solutions -10°C +80°C
Viton Acids, Fats, Hydrocarbons, Vegetable & Mineral Oils, Fuels -5°C +180°C
Polyisoprene Water, Alcohols, Abrasive Substances (Call To Check), Ketones, -10°C +60°C
Silicone Low & High Temperature Resistance Applications -30°C +150°C
High Temp Silicone Super Heated Water -50°C +160°C
Epichlorohydrin Ozone Resistance, Hydrocarbons, Aromatic Oils -25°C +145°C

Take A Seat

Request more information or Advice

Please feel free to request information and advice using the form below or call us on 0151 547 1221
