Stainless Steel ANSI 150 Rotork ROM Actuator Valves

The AV-L6100ROM 2 piece full bore actuated ball valves are available in sizes ranging from 1/2" to 8" for next day delivery. This flanged valve body offers installation between two pipeline flanges and end of line service with a relaible shut off performance. The AV-L6100 actuated ball valve offers TFM 1600 ball seats that are a Wras & FDA certified material. The ISO 5211 mounting pad allows actuation of the valve without the use of a mounting bracket so all assembly and testing procedures can be processed immediately after your order has been placed. Rotork invest heavily in research and development. Their commitment to innovation has resulted in a wide range of solutions across multiple industries including oil & gas, mining, power generation, water treatment and waste management.

Key Features

Key features and benefits of AV-L6100ROM Actuated Ball Valves.
1

Key Features

We assemble and test all of our products in-house so we can control everything and make sure you get a high quality product that will last. All of our products come with a two page test report detailing every aspect of operation including opening/closing times and pressure ratings.
2

Key Features

Whether you are looking for a an electric actuator that is operated continuously throughout the day or infrequently maybe once per month you can rest assured that the Rotork ROM electric actuator will be there to respond and operate your process line when you need it to.
3

Key Features

The Rotork ROM electric actuator features a dust proof and IP68 rated housing and to submersion tested to 10M for 48 hours. The Company's engineering design ensures that the Rotork ROM unit performs well under all conditions including shock, vibration and temperature ranges.

Flanged ANSI 150 Technical Stuff

B C E Model
1/2" 114.00 185.00 108.00 ROM-1
3/4" 114.00 189.00 117.00 ROM-1
1" 114.00 195.00 127.00 ROM-1
1 1/4" 114.00 207.00 140.00 ROM-1
1 1/2" 114.00 212.00 165.00 ROM-1
2" 114.00 251.00 178.00 ROM-A
2 1/2" 196.00 414.00 190.00 ROM-2
3" 196.00 424.00 203.00 ROM-3
4" 196.00 517.00 229.00 ROM-3
5" 232.00 575.00 356.00 ROM-4
6" 232.00 596.00 394.00 ROM-5
8" 232.00 645.00 457.00 ROM-6
10" TBA TBA TBA TBA

Flanged ANSI 150 3D Stuff

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Valve Standards & Stuff

Body Material: ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material: TFM 1600 PTFE Ball Seats
Body Seal Material: Grafoil/316 Stainless Steel
Stem Packing Material: Grafoil
Design Standard: ASME B16.34
Wall Thickness: ASME B16.34
Inspection & Testing: API 598
Face 2 Face: ASME B16.10

Frequent Interrogation

Yes, this Valve is suitable for water within the pressure and temperature limitations.

Not in its current format however we can offer both options. Get in touch through sales@actuation.co.uk or 0151 547 1221 and we will run through some safety options with you for quoting.

It certainly does. All of our actuated valves come complete with a full set of operations and maintenance manuals from both the valve and actuator manufacturers.

Yes! Position feedback is included as standard with switches for open and closed positions.

Maybe. Give us a call to find out.
No.
Most definitely. We will require some more information. Drop us an email or get in touch on the blower.
Yes we can. Plane label or with a big bow. Send us a copy of your delivery note and we will fix it to the box. Jop done.
We will need to talk to Big Tony. If he says you're good for the debt then everything is in order. You can apply for this on the product page or ask for Big Tony when you get in touch.
Request more information or Advice

Please feel free to request information and advice using the form below or call us on 0151 541 8674
