The JJ/TTV Actuated Butterfly Valve assemblies can provide significant total life cost savings for new installations. The Fail Safe Battery Backup option eliminates the need for use of the manual override in the event of a power or system failure to the actuator. Commonly used in critical application lines where failure is not an option. The Actuator will return the Valve to either open or closed position.

Shop

Key features and benefits of the 20W3040JJ Actuated Butterfly Valves.

Key Features

A replaceable valve seat and actuator rated to IP67 complete a robust offering that will go the distance and provide maximum life capacity.

Key Features

The JJ Electric Actuator offers fail in position as well as battery backup failsafe return for critical applications.

Key Features

With over 30 years of experience designing durable, reliable components, you can trust us with your project's success.

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.


Body Material:	GJS500-7 Ductile Iron Rilsan Coated
Seats Material:	EPDM, NBR Buna, Hypalon, Viton, Silicone, High Temperature, Polyisoprene, Epichloridine
Design Standard:	Concentric, Soft Seat
Face To Face:	EN 558 Series 20, ISO 5752 Series 20, API 609 Table 1, BS 5155 Series 4
Pressure Testing:	EN 12266-1, DIN 3230, BS 6755, ISO 5208
Connections:	PN10/16 ANSI 150, ISO 7007, DIN 2501, BS 4504, ANSI Class 150 ANSI B16.5
Sealing Testing:	ISO 5208, 100% Tight Shut Off, API 598

An Electrically Actuated JJ/TTV Butterfly Valve is a flow control device combining a TTV or JJ butterfly valve with an electric actuator for automated on/off or modulating operation. It enables precise control over fluid systems without manual intervention.

These valves are commonly installed in HVAC, water treatment, chemical processing, marine, and general industrial systems where reliable automation and tight shutoff are essential.

Electric actuators offer simple installation, low maintenance, accurate positioning, and quiet operation compared to pneumatic systems. They are ideal for remote or automated process control.

JJ and TTV electric actuators are typically available in 24VDC, 110VAC, and 230VAC versions, ensuring compatibility with most industrial and commercial power setups.

Yes. When fitted with a modulating control unit, they can operate proportionally to a 4–20mA or 0–10V signal for precise flow regulation.

Valve bodies are available in ductile iron, stainless steel, aluminium bronze, and PTFE-lined options, depending on the application. Discs are typically stainless steel, nickel-plated, or bronze for optimal corrosion resistance.

Most JJ/TTV electric actuators are rated IP67, providing protection against dust and temporary immersion in water, suitable for both indoor and outdoor environments.

Common seat options include EPDM, NBR, and PTFE, allowing compatibility with a wide range of media from water and air to more aggressive chemical fluids.

Yes. All standard JJ and TTV electric actuators feature a manual override handwheel, allowing operation during power loss or maintenance.

The range typically covers sizes from DN40 up to DN600, with larger units available upon request depending on the actuator torque and application.

DRAWINGS & SCHEMATICS

CERTIFICATES & APPROVALS

Material	Applications	Temperature
EPDM	Water, Sea Water, Alcohols, Organic Salt Solutions, Mineral Acid Solutions, Mineral Based Alkalines	-20°C +110°C
High Temperature EPDM	Super Heated Water	-20°C +130°C
NBR Buna	Mineral & Vegetable Oils, Gas, Non Aromatic Hydrocarbons, Animal Fats, Vegetable Fats, Air	-10°C +80°C
Hypalon	Mineral Acid Solutions, Organic & In-Organic Acids, Oxidising Solutions	-10°C +80°C
Viton	Acids, Fats, Hydrocarbons, Vegetable & Mineral Oils, Fuels	-5°C +180°C
Polyisoprene	Water, Alcohols, Abrasive Substances (Call To Check), Ketones,	-10°C +60°C
Silicone	Low & High Temperature Resistance Applications	-30°C +150°C
High Temp Silicone	Super Heated Water	-50°C +160°C
Epichlorohydrin	Ozone Resistance, Hydrocarbons, Aromatic Oils	-25°C +145°C
