Double Block and Bleed Valves (DBB) are designed to provide a reliable method of isolating pressure in pipelines and process systems, ensuring zero leakage and enhanced safety during maintenance or system shutdowns. These specialised valves feature two independent seating surfaces (double block) with a bleed port in between, allowing operators to verify that the cavity is pressure-free — a critical function in hazardous and high-risk applications.

Key features and benefits of Double Block and Bleed Valves.

Key Features

Double Block and Bleed Valves offer two independent seating surfaces that isolate pressure from both upstream and downstream sides. This ensures complete system isolation during maintenance or inspection, with no risk of pressure transfer.

Key Features

A bleed port between the two isolation points allows for cavity depressurisation and pressure monitoring. This provides a reliable method to confirm zero pressure before performing downstream work.

Key Features

DBB valves consolidate what would traditionally require two isolation valves and a bleed valve into a single unit. This significantly reduces system weight, installation footprint, and potential leak paths.

Key Features

Designed to API 6D, ASME, and fire-safe standards, DBB valves include features like anti-blowout stems and secondary sealing. These safety mechanisms help protect personnel and equipment in high-risk environments.

Key Features

Available in carbon steel, stainless steel, duplex, and exotic alloys, these valves can be matched to a wide range of media and environmental conditions. This makes them suitable for aggressive, corrosive, or high-temperature applications.

Key Features

With fewer components and high-integrity seating surfaces, DBB valves are engineered for reduced wear and extended service life. Their robust construction means minimal downtime and lower total cost of ownership over time.

Imagine a pipeline with liquid or gas flowing through it. A standard valve shuts off flow from one direction — but what if that valve leaks slightly or pressure builds from the other side?

That’s where a Double Block and Bleed Valve comes in.

It uses two shut-off valves in one body: one stops the flow from the upstream side (the source), and the other stops flow from the downstream side (the output).

These two "blocks" work independently, so even if one fails or leaks slightly, the second one still holds the pressure.

It’s like having two doors locked at either end of a hallway, rather than just one.

This extra layer of safety is essential when dealing with dangerous or high-pressure fluids, gases, or steam — you want complete confidence that nothing is getting through.

Now imagine someone needs to work in that hallway between the two locked doors. Even if both doors are shut, there might still be air or liquid trapped inside. That’s where the bleed valve comes in — a small, third valve located between the two main blocks.

Once both isolation valves are closed, the bleed valve is opened. It lets out anything that’s trapped between the seals — like draining water from a hose before unhooking it.

This ensures that there’s zero pressure left inside, so workers can safely inspect or repair the pipeline without anything unexpected leaking or spraying out.

It's also used to check that the block valves are working properly — if something comes out of the bleed valve, then one of the main seals may not be tight enough.

Once the bleed valve confirms there’s no pressure left in the system — meaning the space between the two blocks is empty — it’s safe for operators or engineers to carry out work downstream.

This might include maintenance on equipment, replacing parts, or simply inspecting the line. Without the Double Block and Bleed setup, there would be no way to confidently guarantee that pressure isn’t building behind the scenes, which could lead to leaks, spills, or even serious accidents.

By using this system, workers can verify with complete certainty that the line is safe, isolated, and empty — all without needing to break into the system first.

Once the job is done, the bleed valve is closed, and the block valves are carefully reopened to resume normal flow.

Industries

Double Block and Bleed Valves are critically important in process systems where safety, environmental compliance, and operational integrity are paramount. Their design ensures complete isolation of pressure from both upstream and downstream sides, with a bleed port that allows operators to safely verify that the cavity between the two seals is fully depressurised. This provides a clear safety advantage over conventional single-valve arrangements, particularly during maintenance or shutdown procedures.

In industries handling hazardous, high-pressure, or high-temperature media—such as oil and gas, chemical processing, and power generation—preventing accidental backflow or pressure release is essential to protect personnel, avoid equipment damage, and minimise environmental risk. These valves also reduce the number of individual components in a system, helping to limit potential leak paths and simplify system design. By combining isolation and venting into one compact unit, Double Block and Bleed Valves streamline operations while maintaining strict compliance with international safety and pressure equipment standards.

Double Block and Bleed Valves are found in critical areas of piping and instrumentation systems where absolute isolation and safety are required. Common locations include upstream and midstream oil and gas pipelines, especially at meter skids, pig launcher and receiver stations, and mainline isolation points. They are also widely used in refinery and petrochemical plants for isolating process lines, during instrument calibration, and for isolating chemical injection points.

In power generation facilities, these valves are used to isolate steam or condensate lines and verify zero-pressure conditions before turbine or heat exchanger maintenance. Marine and offshore platforms use DBB valves in confined or high-vibration environments where compact, fail-safe isolation is necessary. Additionally, you’ll find them in LNG plants, chemical processing units, and anywhere high-integrity isolation is required for compliance with API 6D, OSHA, or other industry regulations.

If you're unsure which Double Block and Bleed Valve is right for your application or need help with sizing, material selection, or compliance requirements — our technical team is here to help.

Get in touch

A Double Block and Bleed (DBB) Valve is a valve assembly that provides two separate sealing surfaces (blocks) and a bleed valve between them. This configuration allows for complete isolation of process flow and safe depressurisation of the valve cavity.

The bleed valve is used to release pressure or drain fluid from the space between the two isolation points. This allows operators to verify that the system is fully isolated before beginning maintenance.

A standard isolation valve only has one shut-off point, which could allow for leakage past the seal. A Double Block and Bleed Valve provides two isolation points and a bleed in between, offering enhanced safety and integrity.

DBB valves are typically used in oil and gas pipelines, refineries, chemical plants, power generation facilities, and offshore platforms—anywhere safe isolation is critical.

Yes, certain Double Block and Bleed valves are rated for high-temperature applications and can be used in steam and condensate systems. Material selection and sealing components must be specified for such use.

Key benefits include improved safety, reduced potential for leakage, compact design, fewer leak paths, and easier compliance with industry standards such as API 6D and OSHA guidelines.

Common types include ball-type Double Block and Bleed Valves, plug valves, gate valves, and modular instrumentation DBB assemblies. The right type depends on application, pressure, temperature, and media.

Yes, many Double Block and Bleed Valves are available with pneumatic, electric, or hydraulic actuators for automated operation, especially in remote or hazardous locations.

They are manufactured in a wide range of pressure classes, typically from ANSI 150 to 2500, and API 3000 to 10000, depending on the application and valve design.

Typical body materials include carbon steel, stainless steel, duplex, super duplex, Inconel, and other exotic alloys for corrosive or extreme service conditions.

Double Block and Bleed valves are pressure tested to verify the integrity of both seals and the cavity bleed function, usually to API 598 or API 6D testing standards.

Many Double Block and Bleed Valves valves are fire-safe certified according to API 6FA or ISO 10497. This ensures that the valve will maintain sealing capability during and after exposure to fire.
