Valpes Actuated Bronze Disc Wafer Butterfly Valves

Valpes Electric Actuators go beyond standard offerings, allowing for custom builds tailored to specific requirements, offering a level of customisation not typically provided by basic standalone Actuator Manufacturers. The 20W3080 Bronze Disc Actuated Butterfly Valves find frequent use in seawater applications, particularly when the external body of the valve is shielded from direct exposure to corrosive environmental elements. These valves are designed with a notable "Dry Shaft" feature, a thoughtful design choice that prevents the medium from making contact with any materials aside from the disc and seat.

Key Features

Key features and benefits of 80WM580 Valpes Actuated Butterfly Valves.
1

Key Features

The aluminium bronze disk of the valve enhances its durability but also ensures the reliability of its performance, especially in harsh seawater conditions.
2

Key Features

The Valpes DV and DVX models highlight specialised features, meeting industry-specific standards and requirements.
3

Key Features

The actuators support multi-voltage operation, providing flexibility in electrical configurations and compatibility with different power sources.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Valve Standards & Stuff

Body Material: ASTM A351 CF8M 316 Stainless Steel & Trim
Seats Material: TFM 1600 PTFE Ball Seats
Design Standard: Grafoil/316 Stainless Steel
Face 2 Face: ASME B16.10
Pressure Testing: EN 12266-1, DIN 3230, BS 6755, ISO 5208
Connections: PN10/16 ANSI 150, ISO 7007, DIN 2501, BS 4504, ANSI Class 150 ANSI B16.5
Sealing Testing: ISO 5208, 100% Tight Shut Off, API 598

Frequent Interrogation

The bronze disc offers excellent corrosion resistance, especially in water, seawater, and mildly corrosive environments. It provides a smooth sealing surface, ensuring long-lasting, low-torque operation and consistent performance.

Not in its current format however we can offer both options. Get in touch through sales@actuation.co.uk or 0151 547 1221 and we will run through some safety options with you for quoting.

Valpes actuators, made in France, are known for robust design, reliability, and smart control options. They are available in ON/OFF, modulating, and failsafe configurations, with IP67 protection and optional communication protocols such as Modbus RTU.

The wafer pattern design allows the valve to be installed between flanges using bolts to align and secure it. This compact style saves space and weight while maintaining strong sealing integrity.

These valves are ideal for marine, HVAC, water treatment, chemical, and general industrial applications where corrosion resistance and automated flow control are important.

Yes. When equipped with the correct actuator model, they support proportional (modulating) control using 4–20mA or 0–10V signals, enabling accurate flow regulation.

Valpes actuators are available in 24VDC, 110VAC, and 230VAC, offering flexibility for different installation environments.

Valpes actuators are rated IP67, providing protection against dust and temporary immersion, suitable for indoor and outdoor installations.

This combination offers compact design, corrosion-resistant construction, reliable automation, and low maintenance, making it an ideal solution for modern process control and water management systems.

Choose Your Rubber

Material Applications Temperature
EPDM Water, Sea Water, Alcohols, Organic Salt Solutions, Mineral Acid Solutions, Mineral Based Alkalines -20°C +110°C
High Temperature EPDM Super Heated Water -20°C +130°C
NBR Buna Mineral & Vegetable Oils, Gas, Non Aromatic Hydrocarbons, Animal Fats, Vegetable Fats, Air -10°C +80°C
Hypalon Mineral Acid Solutions, Organic & In-Organic Acids, Oxidising Solutions -10°C +80°C
Viton Acids, Fats, Hydrocarbons, Vegetable & Mineral Oils, Fuels -5°C +180°C
Polyisoprene Water, Alcohols, Abrasive Substances (Call To Check), Ketones, -10°C +60°C
Silicone Low & High Temperature Resistance Applications -30°C +150°C
High Temp Silicone Super Heated Water -50°C +160°C
Epichlorohydrin Ozone Resistance, Hydrocarbons, Aromatic Oils -25°C +145°C
