Z16 Full Bore Stainless Steel ANSI 150 Floating Pekos Ball Valves

The Z16 Full Bore Stainless Steel ANSI 150 Floating Ball Valves from Pekos are engineered for reliability and clean operation in demanding industrial environments. Constructed from stainless steel, these valves offer excellent resistance to corrosion, making them well-suited for applications involving aggressive chemicals, steam, or sanitary processes. The full bore design maximises flow efficiency while reducing turbulence and pressure loss, contributing to more stable and cost-effective system performance. With a floating ball mechanism for tight shut-off and ANSI 150 compatibility, these valves are ideal for industries such as chemical processing, food and beverage, pharmaceuticals, and marine operations. Precision-crafted and quality-tested, the Z16 range delivers long-term durability and consistent performance.

Key Features

Key features and benefits.
1

Key Features

Made from high-grade stainless steel, these valves offer superior protection against corrosion and chemical attack. This ensures long-lasting operation, even in harsh or hygienic environments.
2

Key Features

The full bore passage allows for unrestricted flow, reducing pressure drop and improving throughput. It also supports easy cleaning and maintenance, especially in sanitary applications.
3

Key Features

The floating ball mechanism guarantees a secure shut-off under varying pressure conditions. This design minimses leakage risks and enhances system safety across a wide range of media.

Pekos Z16 SS ANSI 150 Technical & Dims

PTFE Carbon Graphite A B C D
1/2" Z015FB16TTTGV Z015FB16SSSGV 108.00 185.00 90.00 11.00
3/4" Z020FB16TTTGV Z020FB16SSSGV 117.00 185.00 100.00 12.00
1" Z025FB16TTTGV Z025FB16SSSGV 127.00 185.00 110.00 14.00
1.25" Z032FB16TTTGV Z032FB16SSSGV 140.00 185.00 115.00 15.00
1.5" Z040FB16TTTGV Z040FB16SSSGV 165.00 293.00 125.00 16.00
2" Z050FB16TTTGV Z050FB16SSSGV 178.00 293.00 150.00 17.00
2.5" Z065FB16TTTGV Z065FB16SSSGV 190.00 293.00 180.00 19.00
3" Z080FB16TTTGV Z080FB16SSSGV 203.00 350.00 190.00 21.00
4" Z100FB16TTTGV Z100FB16SSSGV 229.00 350.00 230.00 25.00
5" Z125FB16TTTGV Z125FB16SSSGV TBA TBA TBA TBA
6" Z150FB16TTTGV Z150FB16SSSGV 394.00 740.00 280.00 27.00
8" Z200FB16TTTGV Z200FB16SSSGV 457.00 750.00 345.00 30.00

Pekos Z16 SS ANSI 150 3D Stuff
