Pepperl & Fuchs NBN40-L2-E2-V1 Inductive Sensor

Key Features:

  • Extended 40 mm sensing distance

  • PNP normally open output configuration

  • Operating voltage: 10–30 VDC

  • Rugged rectangular housing

  • IP67-rated for dust and water resistance

  • V1 (M12) connector for easy installation

Operating on 10–30 VDC with a PNP normally open output, the NBN40-L2-E2-V1 is engineered for easy integration into automation systems. It features a rectangular housing design with a robust build, making it suitable for industrial use in harsh environments. With an IP67 protection rating, the sensor provides strong resistance against dust, moisture, and mechanical stress.

Buy Now

Datasheets

  • Document
Datahseets

Pepperl & Fuchs NBN40-L2-E2-V1

Product Specification
Switching function Normally open (NO)
Output type PNP
Rated operating distance 40 mm
Installation Non-Flush
Output polarity DC
Assured operating distance 0 ... 32.4 mm
Actual operating distance 36 ... 44 mm
Reduction factor rAl 0.33
Reduction factor rCu 0.31
Reduction factor r304 0.74
Reduction factor rBrass 0.38
Output type 3-wire

Frequently Asked Questions

It is a long-range inductive proximity sensor designed for non-contact detection of metallic objects in industrial applications.

The NBN40-L2-E2-V1 offers an extended sensing distance of up to 40 mm.

It features a PNP normally open (NO) output.

This sensor operates on 10–30 VDC.

It is built with a robust rectangular housing that allows for stable mounting in demanding environments.

The sensor has an IP67 rating, making it resistant to dust, water, and harsh conditions.

It uses a V1 (M12) connector for quick and secure installation.

It is commonly used in conveyor systems, material handling, assembly lines, and general automation where longer detection ranges are required.

No, inductive sensors like this are designed specifically for metallic object detection.

It detects ferrous metals such as steel most effectively, though it can also detect non-ferrous metals like aluminum and copper at reduced sensing distances.

The 40 mm range allows detection from greater distances, helping to avoid mechanical contact, reduce wear, and improve system longevity.

Yes, its standard output, wide voltage range, and M12 connector make it straightforward to install and integrate into existing setups.
